FARRAR™ CYCLONE™
Introducing the FARRAR CYCLONE: Next Generation Ultra‑Low Temperature Freezers
The FARRAR CYCLONE sets a new standard for ultra-low temperature freezers with its advanced forced-air convection design. Engineered for rapid chilling and efficient storage, the CYCLONE offers flexible temperature setpoints from -20°C to -80°C. Purpose-built to meet precision freezing and storage needs from discovery and pre-clinical to production-scale applications.
FARRAR has once again redefined the leading edge of innovation in refrigeration for the life sciences.
FARRAR® CYCLONE™ 30-Second Product Video
Why choose the FARRAR CYCLONE?
The FARRAR CYCLONE ultra-low temperature freezer unit is designed with a strong focus on life sciences, ensuring exceptional performance. This innovative unit combines ultra-low energy consumption with outstanding cooling capabilities.
As the industry's first forced-air convection freezer and storage chamber, the FARRAR CYCLONE is built for frequent access to stored materials (more than twice per day) while maintaining temperature stability to protect high-value items. The CYCLONE balances sustainability and efficiency with high performance, making it an ideal choice for sensitive materials, especially those involved in pharmaceutical storage.
Unparalleled Cooling Power & Performance
The FARRAR® CYCLONE™ freezer combines sustainability and compliance with advanced cooling power, delivering performance that sets it apart from traditional ultra-low temperature freezer units. With exceptional pull-down, fast door-opening recovery, and unmatched temperature uniformity, CYCLONE offers features that are unheard of in conventional cold wall freezers and standard ULT freezers. Its forced-air convection technology ensures consistent temperature control across the chamber, even during frequent access.
Engineered for Precision and Sustainability in Pharmaceutical Operations
The FARRAR® CYCLONE™ ultra-low temperature freezer is purpose-built for applications that require:
- Regular access to stored materials (more than twice daily)
- Temperature stability to protect high-value materials from temperature excursions caused by frequent door openings or transient warming
- Short-term freezing and storage in a single chamber
- Adjustable setpoints across a wide temperature range
- A balance of energy efficiency, low-GWP refrigerants, and reliable performance
- Optimised storage capacity within a minimal footprint
| Flexible temperatures | Adjustable temperature (-20°C to -80°C |
|---|---|
| Unparalleled performance | Fast temperature recovery after opening |
| Complaint | Low GWP and energy efficient |
| Integrated systems | Integrated with systems such as BAS & BMS |
| Application | Freezing & Storage, Frequent Access Storage, Bulk Drug Storage, CGMP Cold Storage Operations, Biobanking |
|---|---|
| Chamber Volume | 934L (33 cu. ft.), 630 2" Boxes |
| Temperature Range | -20°C to -80°C |
| Ambient Operating Temperature | 10°C to 32°C |
| Total Interior volume | 934L (33 cu. ft.) |
|---|---|
| Interior Dimensions | 749.3mm x 965.2mm x 1295.4mm (29.5" x 38" x 51") |
| Exterior Dimensions | 1187.5mm x 1168.4mm x 1968.5mm (46.75" x 46" x 77.5") |
| Unit Weight | 950 lbs. / 430.91 kg estimated | Shipping Weight | 1250 lbs. / 566.99 kg estimated |
