New Benchtop Autoclave
Introducing the Benchtop Autoclave from Haier Biomedical
Haier's Benchtop Autoclave is designed to maximise efficiency in the sterilisation process. It is ideally suited for industries such as life sciences, healthcare, and other technical fields where disinfection and sterilisation are essential. We are excited to welcome the Haier Benchtop Autoclave to our product portfolio.
This autoclave is ideal for facilities with limited space, as it features a large water tank while maintaining a compact design that is suitable for benchtop workflows. You'll find this instrument in various healthcare settings, including ophthalmology, stomatology, veterinary care and diagnostic laboratories.
Haier has engineered this autoclave to be particularly suitable for biomedical applications, where lab equipment may come into contact with blood, body fluids, and other biological materials.
Key Benefits and Features of the Haier Benchtop Autoclave
Compact Design: This unit features a space-saving design that enhances lab efficiency without compromising on size. Haier has successfully integrated a large water storage tank within a standard-sized unit, enabling optimal turnaround times and workflow rates.
Safety Protocols: The unit is equipped with a high safety rating and features multiple safety measures, including over-voltage protection, leak detection, anti-drying protection, and sensor disconnection detection. Additionally, it has door safety features, including a thermally insulated cover.
Optimised Efficiency: The Benchtop Autoclave achieves rapid sterilisation thanks to its significantly reduced drying time, which is facilitated by a pressure blast system. The high-performance steam generator quickly raises the temperature, and the unit also features a vacuum-forced cooling system.
Integrated Temperature and Pressure Monitoring: The system offers triple protection for temperature and pressure. The set pressure is continuously monitored. If pressure exceeds normal range, the electronic lock will deactivate, automatically releasing pressure through the safety valve.
Explore the Key Advantages of the Haier Benchtop Autoclave:
Triple Protection
- Pressure and temperature monitoring with an electronic lock and mechanical safety device.
- When the set pressure is exceeded, the safety valve opens automatically to release the pressure.
Rapid Sterilisation Time
- Optimised vacuum cooling and blast drying system ensures fast, effective sterilisation, significantly reducing cycle times while enhancing drying performance.
Optional-Intelligent IoT Module
- The mobile app monitors and reports the Benchtop Autoclave's running status in real time.
Programmable Mode
- The Haier benchtop autoclave features a 4-inch full-colour TFT LCD screen, making graphics and figures clear at a glance, and easy to use.
New Steam Technology and Large Water Storage Tank
- An efficient steam generator with high heat exchange efficiency and large gas output is adopted to reach rapid temperatures and sterilise equipment.
- Open water storage tank, easy to clean. High water level display and low water level alarm.
Why choose a Benchtop Autoclave from Haier?
With over 500 intellectual property patents, more than 300 certified medical devices, and a presence in over 140 countries, the Haier Benchtop Autoclave leads the way in innovation and development, ensuring the highest quality and efficiency in medical devices.
Haier prioritises user experience in the design of its benchtop autoclave, taking into account all user needs for disinfection and sterilisation tasks. Laboratories face pressure to operate both efficiently and effectively, and this benchtop autoclave is optimised to minimise operating times.
Benefit from its compact design and high completion rates, regardless of your application.
Full Product Specification:
Model | HRTM-18 | HRTM-23 |
Design Pressure (Mpa) | 0.28 | 0.28 |
Design Temperature(ºC) 2.5 | 150 | 150 |
Rated Working Pressure (Mpa) | 0.22 | 0.22 |
Sterilization Temperature Range (ºC) | 105-138 | 105-138 |
Temperature Control Precision (ºC) | ±0.1 | ±0.1 |
Sterilization Time Range (min) | 0~999 | 0~999 |
Power Supply (V/Hz) | 220-240~50/60 | 220-240~50/60 |
Power (W) | 2800 | 3200 |
Capacity (L) | 18 | 23 |
Weight (KG) | 47 | 53 |
Interior Dimension (mm) | φ247*350 | φ247*450 |
Exterior Dimension (W*D*H) (mm) | 490*600*455 | 490*690*455 |
Cabinet and Door Material | SUS304 | SUS304 |
Autoclave Servicing & Validation
Maintaining the performance and compliance of your Haier Benchtop Autoclave is essential. At Withnell Sensors, we offer full autoclave servicing and validation,n for healthcare, laboratory, pharmaceutical, and research sectors. Our comprehensive service packages include a range of operational and condition checks designed to maintain safety, functionality, and performance, helping you meet regulatory requirements and ensure consistent sterilisation results.
Benchtop Autoclave Servicing Includes:
- Routine servicing and calibration by experienced engineers
- Temperature mapping
- Validation to HTM 01-05 and other regulatory standards
- Detailed service reports and certification
- On-site visits to suit your schedule
What’s Checked During an Autoclave Service?
Component | Service Check Details |
Door and chamber | Checked for wear, damage or leaks to ensure safe, sealed operation |
Pressure relief valve | Tested to confirm safe pressure release |
Filters | Cleaned or replaced to maintain airflow and performance |
Reservoirs, sensors & drainage | Assessed for blockages or faults |
Internal pipes | Inspected for build-up, leaks or corrosion |
Fuses, relays and boards | Checked for safe and reliable function |
Solenoid valves | Tested for correct flow and operation |
Vacuum pump (if applicable) | Checked for effective air removal |
Water pump | Reviewed for flow rate and condition |
Heating element/boiler | Assessed for performance and efficiency |
Temperature and pressure instruments | Calibrated for accuracy and compliance |
Need support with your autoclave?
Speak to our team today to arrange servicing or validation: [email protected]
Independent Advice
Our team at Withnell Sensors are here to help, every step of the way. We offer expert advice and technical guidance, with engineers experienced in autoclave equipment and the varied industry-specific requirements. From selecting the right autoclave to ongoing after-sales support, we're committed to ensuring your equipment integrates smoothly and performs reliably.
